1181C-SL005

Multi-Conductor Cable Polyvinyl Chloride 12 Conductors 22AWG 7.28mm 300VAC - Slate - 30.48m (100ft)/Spool .. see full description

RoHS Compliant

Packaging

Accessories

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

1181C-SL005

Alias/AKA:

1181C-SLATE-100

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Number of Conductors:

Conductor Material:

Tinned Copper

Cable Length:

30.48 m

Maximum Current Rating:

N/A

Type:

Multi-Conductor Cable

The 1181C-SLATE-100 is a multi-conductor cable designed for communication and control applications. It consists of 12 color-coded, 22 AWG stranded (7/30) tinned copper conductors, each with a 0.010-inch PVC insulation wall. The cabled core has a minimum twist rate of 4.0 twists per foot and is protected by a durable, slate-colored PVC jacket with a nominal thickness of 0.032 inches, resulting in an overall nominal diameter of 0.272 inches. This cable has a voltage rating of 300 VRMS and an operating temperature range of -20Â°C to 80Â°C. Its UL Type CM and CSA Type CMG ratings make it suitable for general-purpose instrumentation and control systems.
