2844/19-WH001

Name: 2844/19-WH001
Brand: Alpha Wire
SKU: 10121302
Price: 1034.46 USD
Availability: OutOfStock

Alpha Wire

A 24 AWG single-conductor hook-up wire featuring a stranded silver-plated copper conductor and high-temperature PTFE insulation. .. see full description

RoHS Compliant

Packaging

Accessories

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

Alpha Wire

Part No:

2844/19-WH001

Alias/AKA:

2844/19-WHITE-1000

RoHS:

Yes

HTS:

8544493080

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

Size:

24 AWG

Bunch Stranding:

19x36

Conductor Material:

Silver Plated Copper

Cable Diameter:

0.94 mm

Maximum Voltage Rating:

250 V

Operating Temperature:

-60 to 200 °C

Color:

White

The 2844/19-WH001 is a high-performance hook-up wire compliant with MIL-W-16878/6 (Type ET) specifications. It is constructed with a 24 AWG (19/36) stranded silver-plated copper conductor and a 0.006-inch nominal wall of white PTFE insulation. This construction provides a wide operating temperature range from -60Â°C to 200Â°C and a voltage rating of 250 VRMS. Its durability and stable electrical properties make it suitable for internal wiring in demanding electronic, military, and aerospace applications.
