AZ8-1CH-6DE by american zettler
Image is representational - see mfr. specs
DATA SHEET

AZ8-1CH-6DE

American Zettler

Mini PC Board Relay 6VDC coil SPDT .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ8-1CH-6DE
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
6 V
Contact Arrangement:
SPDT10703
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-55 to 90 °C
Coil Resistance:
80 Ohm
The AMERICAN ZETTLER part AZ8-1CH-6DE is a compact and versatile mini PC board relay designed for reliable performance in various applications. It features a 6VDC coil and a single-pole double-throw (SPDT) configuration, allowing for flexible switching capabilities. This relay is ideal for compact electronic devices and can handle different voltage levels with ease. Trustworthy and durable, it is a valuable component that ensures reliable operation in your electronic projects.
Search Keywords:
AZ81CH6DE
IN STOCK: 280
Ships today, if you order in
Minimum Order Quantity:
20
Multiple:
20
Factory Lead-Time
15 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
20
$2.20
$44.00
40
$2.18
$87.20
60
$1.72
$103.20
80
$1.71
$136.80
1,000 +
$1.34
$1,340.00
Suppliers Standard Package
