AZ850-5 by american zettler
Image is representational - see mfr. specs
DATA SHEET

AZ850-5

American Zettler

Electromechanical Relay DPDT 1A 5VDC 178Ohm Through Hole .. see full description

RoHS Compliant
Tube Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ850-5
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Tube
Relay Construction:
Non-Latching
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
14 x 9 x 5 mm
Termination Style:
PC Pin
Coil Current:
28 mA
Contact Form:
2 Form C
The AMERICAN ZETTLER part AZ850-5 is an electromechanical relay with DPDT (Double Pole Double Throw) configuration. It has a contact rating of 1A and operates at a voltage of 5VDC. The relay has a resistance of 178 Ohm and can be mounted through hole. This versatile and reliable relay is suitable for various applications where low voltage switching is required.
Search Keywords:
AZ8505
IN STOCK: 610
Can Ship immediately
Minimum Order Quantity:
50
Multiple:
50
Factory Lead-Time
9 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
50
$1.79
$89.50
250
$1.42
$355.00
500
$1.32
$660.00
1,000
$1.23
$1,230.00
2,500
$1.22
$3,050.00
5,000
$1.14
$5,700.00
7,500
$1.13
$8,475.00
10,000 +
$1.12
$11,200.00
Suppliers Standard Package
