AZ9731-1C-24DC3E by american zettler
Image is representational - see mfr. specs
DATA SHEET

AZ9731-1C-24DC3E

American Zettler

The AZ9731-1C-24DC3E is a 40A, SPDT (Single Pole Double Throw) mini-ISO automotive relay with a 24VDC coil. .. see full description

RoHS Compliant
Tray Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
American Zettler
Part No:
AZ9731-1C-24DC3E
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Package Type:
Tray
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
40A (NO) / 30A (NC)
Coil Voltage:
24 VDC
Coil Current:
66.67 mA
Coil Resistance:
360 Ohm
Contact Material:
Silver Tin Oxide
Must Operate Voltage:
15.6 VDC
Must Release Voltage:
3.6 VDC
Operate Time:
7 ms
Seal:
Sealed
Mounting:
Socket
Termination Style:
Quick Connect
Dimension:
26.5 x 26.5 x 36 mm
Operating Temperature:
-40 to 125 °C
Packaging:
N/A
The AZ9731-1C-24DC3E is a high-current, mini-ISO automotive relay featuring a Single Pole Double Throw (SPDT) contact arrangement. It operates with a nominal 24VDC coil and supports a contact rating of 40A for the normally open side and 30A for the normally closed side. This relay is designed for durability with a sealed plastic dust cover and can function across a wide operating temperature range of -40°C to 125°C. With quick connect terminals and a maximum operate time of 7ms, it is well-suited for various automotive power switching applications.
Search Keywords:
AZ97311C24DC3E
IN STOCK: 0
On Order:
415   can ship 7/1/26
MOQ for In Stock Qty:
10
MOQ for out of Stock Qty:
100
Factory Lead-Time
20 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
10
$3.12
$31.20
25
$3.11
$77.75
50
$3.10
$155.00
100
$3.09
$309.00
200
$2.33
$466.00
300
$2.17
$651.00
400 +
$2.13
$852.00
Suppliers Standard Package
