AWHW-10G-SMD by assmann wsw components
Image is representational - see mfr. specs
DATA SHEET

AWHW-10G-SMD

Assmann WSW Components

Conn Shrouded Header HDR 10 POS 2.54mm Solder ST SMD .. see full description

RoHS Compliant
TRAY Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Assmann WSW Components
Part No:
AWHW-10G-SMD
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
28
Package Type:
TRAY
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
2.54 mm
Number of Contacts:
10
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3 A
Termination Method:
Solder
Operating Temperature:
-40 to 105 °C
The Assmann WSW Components AWHW-10G-SMD is a shrouded header with a 10-position configuration. This surface mount device (SMD) features a 2.54mm solder tail pitch for easy assembly on circuit boards. The header is designed to securely connect wires or cables, offering a reliable and compact solution for various electronic applications. With its high-quality construction and soldering capability, the AWHW-10G-SMD is an ideal choice for professionals in need of a dependable and efficient connector.
Search Keywords:
AWHW10GSMD
IN STOCK: 1,483
Can Ship immediately
On Order:
952   can ship 6/8/26
Minimum Order Quantity:
28
Multiple:
28
Factory Lead-Time
17 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
28
$0.71
$19.88
56
$0.68
$38.08
112
$0.64
$71.68
224
$0.61
$136.64
11,200
$0.58
$6,496.00
22,400 +
$0.55
$12,320.00
Suppliers Standard Package
Please Note: Tariffs may apply for U.S. shipments
