95A1A-B28-A13L by bourns
Image is representational - see manufacturer specifications
DATA SHEET

95A1A-B28-A13L

Bourns

Res Cermet POT 5K Ohm 10% 2W 1(Elec)/1(Mech)Turn 6.35mm (34.93 X 15.88 X 22.55mm) Solder Lug Panel Mount .. see full description

RoHS Compliant
TRAY Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
95A1A-B28-A13L
RoHS:
Yes
HTS:
8533408050
COO:
MX
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
45
Package Type:
TRAY
Mounting:
Panel Mount
Number of Turns:
1(Elec),1(Mech) Turns
Termination Style:
Solder
Power Rating:
2 W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±150 ppm/°C
Dimension:
34.93 x 15.88 x 22.55 mm
Operating Temperature:
-40 to 125 °C
Switch Option:
No
Number of Elements:
1
The 95A1A-B28-A13L is a Model 95 single-turn panel control potentiometer featuring triangle-pattern solder lugs and a 7/8" (28 mm) metal plain bushing with a 10 mm diameter and 9 mm length. This device uses a cermet resistive element with a linear taper (H code) and ±5% tolerance, supporting resistance values from 100 ohms to 1 megohm. The potentiometer is available with standard shaft lengths of 16.0 mm (0.630") or 22.0 mm (0.866"), with shaft type "V" dimensions of 1.50 ± 0.25 mm diameter. It features virtually infinite electrical circuit isolation and is RoHS compliant, making it suitable for audio equipment, industrial control panels, and consumer electronics requiring precise resistance adjustment with reliable solder lug termination.
Search Keywords:
95A1AB28A13L
IN STOCK: 72
Ships today, if you order in
Minimum Order Quantity:
45
Multiple:
45
Factory Lead-Time
7 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
45
$5.14
$231.30
90
$4.95
$445.50
135
$4.94
$666.90
270
$4.79
$1,293.30
540
$4.78
$2,581.20
1,035
$4.73
$4,895.55
2,520
$4.67
$11,768.40
5,040 +
$4.66
$23,486.40
