GMOV-20D321K
Bourns20 mm hybrid protection component combining GDT and MOV technologies for bidirectional surge protection with low leakage and low capacitance. .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
GMOV-20D321K
RoHS:
Yes
HTS:
8533408050
COO:
CN
ECCN:
EAR99
Supplier's Standard Package
250
Package Type:
BOX
GMOV-20D321K is a 20 mm hybrid protection component that combines Bourns' patented GDT with FLAT technology and a Metal Oxide Varistor (MOV) for superior surge protection. It features a maximum operating voltage (MCOV) of 320 Vrms, MOV voltage of 510 V (±10%), and GDT DC breakdown voltage of 500 V (475–650 V range). The device offers bidirectional protection with low leakage (< 1 µA), low capacitance, and an energy rating of 360 J at 8/20 µs. With a protection level of 1,300 V and clamp voltage of 875 V, it is UL Type 5 recognized and compliant with UL 1449 4th Edition. This component is ideally suited for AC and DC power applications including solar inverters, power supplies, white goods, and SPD systems where long-life protection with high performance is required.
Search Keywords:
GMOV20D321K
IN STOCK:
1,000
Can Ship immediately
Minimum Order Quantity:
250
Multiple:
250
Factory Lead-Time
25 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
250
$1.85
$462.50
500
$1.39
$695.00
1,000
$1.35
$1,350.00
2,500
$1.34
$3,350.00
5,000
$1.33
$6,650.00
7,500
$1.32
$9,900.00
10,000
$1.31
$13,100.00
15,000
+
$1.30
$19,500.00
