Supplier:
Bourns
Part No:
SMCJ58CA
RoHS:
No
HTS:
8541100070
COO:
TW
ECCN:
EAR99
Supplier's Standard Package
3000
Package Type:
REEL
Maximum Peak Pulse Current:
16 A
Dimension:
7.11(Max) x 6.22(Max) x 2.42(Max) mm
Maximum Clamping Voltage:
93.6 V
Family:
CD214C-T58CA
Direction Type:
Bi-Directional
SMCJ58CA is a bidirectional transient voltage suppressor diode designed for surge and ESD protection in portable communications, computing, and video equipment applications. This device features a working peak reverse voltage of 58 V, a breakdown voltage of 64.4 V, and a maximum reverse voltage rating of 74.6 Vrms, with a compact SMC (DO-214AB) surface mount package. The diode delivers peak pulse power dissipation of 1500 watts at a 1 ms pulse width and maintains steady-state power dissipation of 5.0 watts at 75°C, with typical response times under 5.0 nanoseconds for bidirectional operation. Lead-free and RoHS compliant, the SMCJ58CA operates reliably across a temperature range of -55°C to +150°C, making it ideal for protecting sensitive circuits from transient voltage events in compact electronic designs.
Search Keywords:
SMCJ58CA
This product is NOT RoHS Compliant. See Alternatives
IN STOCK:
7,005
Can Ship immediately
Minimum Order Quantity:
1000
Factory Lead-Time
14 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1,000
$0.2547
$254.7000
3,000
$0.2433
$729.9000
6,000
$0.2296
$1,377.6000
9,000
$0.2233
$2,009.7000
12,000
$0.2227
$2,672.4000
27,000
$0.2145
$5,791.5000
51,000
+
$0.2090
$10,659.0000
