AFB02512HHA-A by delta thermal / emi / solenoids
Image is representational - see mfr. specs
DATA SHEET

AFB02512HHA-A

Delta Thermal / EMI / Solenoids

DC Fans - DC Axial Fan - 25x10mm - 12VDC .. see full description

RoHS Compliant
Packaging
Accessories
Discontinued & Replaced
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB02512HHA-A
RoHS:
Yes
HTS:
8414599080
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
720
Category:
DC Fan
Dimension:
25 x 25 x 10 mm
Voltage Rating:
12 V
Power Rating:
0.96 W
Maximum Airflow:
2.4 CFM
Noise Level:
28 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A
Life Cycle:
Discontinued & Replaced
The AFB02512HHA-A is a DC Fan. Voltage - Rated 12VDC Size / Dimension Square - 25mm L x 25mm H Width 10.00mm Air Flow 2.4 CFM (0.067m³/min) Static Pressure 0.300 in H2O (74.7 Pa) Bearing Type Ball Fan Type Tubeaxial Features - Noise 28.0 dB(A) Power (Watts) 960mW RPM 13000 RPM Termination 2 Wire Leads Ingress Protection - Operating Temperature 14 ~ 158°F (-10 ~ 70°C) Approvals CE, CSA, UL, VDE Weight 0.023 lb (10.43g) Current Rating (Amps) 0.080A Voltage Range 7 ~ 13.2VDC Material - Frame Plastic Material - Blade Plastic
Search Keywords:
AFB02512HHAA
  This product is discontinued, but still in stock
IN STOCK: 80
Can Ship immediately
Minimum Order Quantity:
5
Price (USD)
Quantity
Unit Price
Ext. Price
5
$10.969
$54.845
25
$9.035
$225.875
50
$8.891
$444.550
100
$8.487
$848.700
250
$7.999
$1,999.750
720
$7.775
$5,598.000
1,440 +
$7.563
$10,890.720
Suppliers Standard Package
RECOMMENDED REPLACEMENT
AFB02512HHA-C
AFB02512HHA-C
