AFB0512VHD by delta thermal / emi / solenoids
Image is representational - see manufacturer specifications
DATA SHEET

AFB0512VHD

Delta Thermal / EMI / Solenoids

Axial Square-50mm L x 50mm H x 20mm W 12VDC 2 Wire Leads .. see full description

RoHS Compliant
Box Packaging
Accessories
End of Life: Final orders must be placed by 09/01/2028
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB0512VHD
RoHS:
Yes
HTS:
8414596590
COO:
CN
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
252
Package Type:
Box
Category:
DC Fan
Dimension:
50 x 50 x 20 mm
Voltage Rating:
12 V
Power Rating:
1.92 W
Maximum Airflow:
20.3 CFM
Noise Level:
40.5 dB
Special Features:
None
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
N/A
End of Life:
Final orders must be placed by 09/01/2028
The AFB0512VHD is a DC Axial Fan Voltage - Rated 12VDC Size / Dimension Square - 50mm L x 50mm H Width 20.00mm Air Flow 20.3 CFM (0.568m³/min) Static Pressure 0.303 in H2O (75.5 Pa) Bearing Type Ball Fan Type Tubeaxial Noise 40.5 dB(A) Power (Watts) 1.92W RPM 7000 RPM Termination 2 Wire Leads Approvals CE, CSA, UL, VDE Weight 0.084 lb (38.1g) Current Rating (Amps) 0.160A Voltage Range 7 ~ 13.8VDC Material - Frame Plastic Material - Blade Plastic
Search Keywords:
AFB0512VHD
  End of Life: Final orders must be placed by 09/01/2028
IN STOCK: 0
Minimum Order Quantity:
5
Factory Lead-Time
32 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$13.51
$67.55
25
$12.75
$318.75
50
$12.63
$631.50
100
$12.51
$1,251.00
250
$11.83
$2,957.50
504
$10.92
$5,503.68
1,008 +
$10.86
$10,946.88
