S506-1-R by eaton electronics / bussmann
Image is representational - see manufacturer specifications
DATA SHEET

S506-1-R

Eaton Electronics / Bussmann

Fuse - Miniature - Slow Blow Acting - 1A - 250V - Holder - Cartridge - 5 X 20mm - Glass .. see full description

RoHS Compliant
OTHER Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Eaton Electronics / Bussmann
Part No:
S506-1-R
RoHS:
Yes
HTS:
8536100020
COO:
PH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
OTHER
Type:
Miniature
Fuse Size:
5 x 20 mm
Acting:
Slow Blow
Current Rating:
1 A
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
N/A
Fuse Material:
Glass
Mounting:
Holder
The S506-1-R is a miniature fuse to protect your electronics. This device has a current rating of 1A. It has 2 terminals. The S506-1-R fuse has a cartridge termination style. The maximum AC voltage rating is 250 VAC. Its fuse is made from glass. This product is 20 mm long with a diameter of 5.2 mm.
Search Keywords:
S5061R
  Different packaging options available.  See Alternatives
IN STOCK: 0
Minimum Order Quantity:
16
Factory Lead-Time
16 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
16
$5.42
$86.72
50
$4.41
$220.50
100
$4.21
$421.00
250
$4.09
$1,022.50
500
$3.86
$1,930.00
1,000
$3.76
$3,760.00
2,500
$3.66
$9,150.00
5,000 +
$3.62
$18,100.00
Click for Quote
