11CX2

The HONEYWELL part 11CX2 is a MICRO SWITCHâ„¢ Hazardous Location Switch designed for use in demanding environments. It features a durable epoxy-coated aluminum short housing with a side rotary design and momentary action. The switch includes two single pole double throw (SPDT) basic switches, each with a 15 Amp rating at 125, 250, or 480 Vac. With a NEMA 1, 3, 4, 4X, 6, 6P, 13, and IP66 seal rating, this switch is suitable for use in a variety of indoor and outdoor applications. It is capable of operating in temperatures ranging from -25 Â°C to 85 Â°C (-13 Â°F to 185 Â°F). The 11CX2 switch features (2) 3/4 in - 14 NPT conduit terminations, allowing for easy installation and connection to electrical systems. It is also approved for use in hazardous locations, with NEMA 7 (Class I, Div. 1 & 2, Groups C & D) and NEMA 9 (Class II, Div. 1 & 2, Groups E, F, & G) certifications. This switch has received agency approvals from UL and CSA, ensuring its compliance with safety and performance standards. It also includes an internal ground screw for proper grounding. Overall, the HONEYWELL part 11CX2 is a reliable and versatile switch that is suitable for hazardous locations and provides excellent performance in challenging environments.

Product Highlights:

Sealing - applicable portions of NEMA 1, 3, 4, 4X, 6, 6P, 7, 9, and 13
Watertight and dust-tight for outdoor use
4 mA to 20 mA analog output available
UL Listed, file #E14274
Analog UL file #E68247
CSA Certified, file #LR57324
Rugged, cast aluminum housing
Pretravel, overtravel, and actuating sequence can be field adjusted without tools (all basics individually)
Rotary types convert in seconds to clockwise, counter-clockwise, or both-way operation

Potential Applications:

<ul><li> Control valves and actuators</li><li> Petro-chemical plants</li><li> Grain handling</li><li> Waste treatment</li><li> Hazardous waste handing</li><li> Power generating</li><li> Paint facilities</li></ul>

Search Keywords:

11CX2
