1EN1-S by honeywell
Image is representational - see manufacturer specifications
DATA SHEET

1EN1-S

Honeywell

Snap Action Switch - SPDT x 2 - On-Mom - 4A, 28VDC - Round (Pin Plunger) Actuator - 2722 to 5443gf Operating Force - Screw Terminal - Panel Mount. .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1EN1-S
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
Enclosed
Actuator Style:
Top Plunger
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Operating Force:
53.38 N
Dimension:
25.4 x 25.4 x 72.39 mm
Maximum Current Rating:
4@28VDC A
Terminal Type:
Screw
NEMA Standard as Enclosure Rating:
N/A
Body Orientation:
Straight
The 1EN1-S from HONEYWELL is panel mount single pole double throw (SPDT) snap action switch with On-Mom switch function and screw terminal. This switch has round (pin plunger) actuator, operating force range from 2722 to 5443gf and overtravel of 0.250" (6.35mm). Operating temperature range is from -54°C to 85°C.
Product Highlights:
  • Meets or exceeds mechanical and electrical life as defined in MIL-S-8805
  • Top plunger and roller plunger actuators have an internal ice scraper ring
  • Variety of actuators and terminations
  • Variety of contact options and contact materials
  • Stainless steel housing
Potential Applications:
<ul><li>Aircraft landing gear and flap/stabilizer controls</li><li>Aircraft engine thrust reversers</li><li>Space vehicles</li><li>Armored personnel carriers</li></ul>
Search Keywords:
1EN1S
IN STOCK: 62
Can Ship immediately
MOQ for out of Stock Qty:
3
Factory Lead-Time
16 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$771.34
$771.34
3
$763.70
$2,291.10
5
$756.13
$3,780.65
8
$754.24
$6,033.92
10 +
$732.18
$7,321.80
Click for Quote
