1SE1-3
HoneywellMICRO SWITCH™ Miniature Environmentally Sealed Basic Switches: SE Series, Single Pole Double Throw (SPDT), 5 A at 250 Vac, Stainless Steel Pin Plunger, (3) 914 mm [36 in] Lead Wire Termination (20 Gage), -53 °C to 105 °C [-65 °F to 221 °F] Temperature Range .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1SE1-3
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Supplier Standard Pack
1
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Plunger
Contact Rating @ Voltage:
5@250VAC 30VDC A
Maximum Movement Differential:
0.1 mm
Operating Force:
4.73 N
Termination Style:
Wire Lead
Dimension:
22.25 x 8.79 x 18.92 mm
Body Orientation:
Straight
IP Rating:
N/A
<p>Snap Action Switches, which are also known as micro switches, is a type of momentary contact switch that can rapidly change positions responding to small movements. A Snap Action Switch operates at a rapid speed as it takes very little force or stimulus to operate. This SPDT Snap Switch is widely used in aircraft, ordinance, moist or dusty industrial environments.</p><p>1SE1-3 Snap Action Switch from Honeywell comes with SPDT circuitry and a power load switching capability of 7A. This Honeywell switch has a high temperature tolerance up to 149 °C and comes in a very small package size. This environment-sealed basic switch comes with a choice of actuation for design flexibility and precision functionality.</p>
Product Highlights:
- Choice of actuation
- Temperature tolerance to 105 °C [221 °F]
- High temperature construction for use to 149 °C [300 °F]
- Watertight seal per MIL-PRF-8805, enclosure design symbol 3
- Very small package size
- Power load switching capability to 7 A
Search Keywords:
1SE13
IN STOCK:
10
Ships today, if you order in
Factory Lead-Time
18 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$108.38
$108.38
5
$106.26
$531.30
10
$88.43
$884.30
20
$87.99
$1,759.80
50
$87.55
$4,377.50
100
+
$87.11
$8,711.00
