1SX1-H58 by honeywell
Image is representational - see mfr. specs
DATA SHEET

1SX1-H58

Honeywell

MICRO SWITCH™ Subminiature Basic Switches: SX Series, Single Pole Double Throw (SPDT), 7 A at 250 Vac, Pin Plunger Actuator, Quick Connect Terminals Mate with AMP .058 in Receptacle .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1SX1-H58
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Pin Plunger
Contact Rating @ Voltage:
7@250VAC A
Maximum Movement Differential:
0.13 mm
Operating Force:
1.39 N
Termination Style:
Quick Connect
Dimension:
12.7 x 5.08 x 14.86 mm
Body Orientation:
Straight
IP Rating:
N/A
<p>Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. They are generally used in aerospace, appliances, vending machines, computer and business equipment, test instruments, medical and dental equipment, communications equipment and HVAC equipment. </p><p>1SX1-H58 Snap Action Switch from Honeywell comes with long operating life and elongated mounting hole for easier and accurate mounting. This sub-miniature Pin Plunger Switch comes with a choice of actuation, electrical termination, and operating characteristics to provide design flexibility.</p>
Product Highlights:
  • The Honeywell Snap Switch has long operating life
  • Elongated mounting hole for easier, more accurate mounting
  • Choice of actuation (plunger, as well as a variety of integral and auxiliary actuators)
  • Optional series constructions available (gold contacts for low energy switching, bifurcated gold contacts for maximum reliability, power load switching capability to 7 A)
  • MIL-PRF-8805 qualified listings available
  • Choice of electrical termination (solder, quick connect, PCB)
  • Choice of operating characteristics
Potential Applications:
<ul><li>Aerospace</li><li>Appliances</li><li>Vending machines</li><li>Timing devices</li><li>Office equipment</li><li>Computer/business equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>Communications equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li></ul>
Search Keywords:
1SX1H58
IN STOCK: 102
Can Ship immediately
On Order:
200   can ship 5/7/26
Factory Lead-Time
7 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$29.75
$29.75
10
$27.51
$275.10
25
$27.30
$682.50
50
$21.99
$1,099.50
200
$20.85
$4,170.00
400
$20.63
$8,252.00
600 +
$19.27
$11,562.00
