1TL1-3D by honeywell
Image is representational - see mfr. specs
DATA SHEET

1TL1-3D

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Single Pole Double Throw (SPDT) 2 Position (On - On), Screw Terminals, Locking Lever (Locked Out Of Center Position), Military Part Number MS24658-23D .. see full description

RoHS Compliant
Box Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
1TL1-3D
Alias/AKA:
MS24658-23D
RoHS:
Yes
HTS:
85365000
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Box
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
20@28VDC A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
28.4 x 15.7 x 72.9 mm
Operating Temperature:
-65 to 72 °C
<p>Toggle Switches are manually actuated by means of a projecting lever, such as mechanical lever, handle or a rocking mechanism. These electrical switches are available in many different styles and sizes. They are generally used in military and commercial aviation, agricultural machinery, and process control applications.</p> <p>1TL1-3D Honeywell Switch features environment-proof sealing and has pull-to-unlock levers. The switching chambers are completely sealed, while its step-design case offers an extra space between the terminals to help prevent shorting. With a temperature range between -85°F to +160°F, Honeywell 1TL1-3D enables both maintained and momentary toggle action. This On On SPDT Switch is used in industrial machinery and equipment, construction equipment, test instruments and medical instrumentation.</p>
Product Highlights:
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
  • Temperature range: -85°F to +160°F
  • Qualified to MIL-DTL-3950
  • Environment-proof sealing
  • 1, 2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Completely sealed switching chamber
Potential Applications:
<ul><li>Industrial machinery and equipment</li><li>Military and commercial aviation</li><li>Construction equipment</li><li>Test instruments</li><li>Agricultural machinery</li><li>Process control</li><li>Medical instrumentation</li></ul>
Search Keywords:
1TL13D
IN STOCK: 1,048
Can Ship immediately
Factory Lead-Time
6 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$54.29
$54.29
5
$48.45
$242.25
10
$44.19
$441.90
25
$43.22
$1,080.50
50
$42.40
$2,120.00
100
$41.99
$4,199.00
250 +
$41.36
$10,340.00
