2TL1-5F by honeywell
Image is representational - see mfr. specs
DATA SHEET

2TL1-5F

Honeywell

MICRO SWITCH™ Toggle Switches: TL Series, Double Pole Double Throw (DPDT) 3 Position (Mom. On - Off - On), Screw Terminals, Locking Lever (Locked In Extreme Position, Opposite Keyway), Military Part Number MS24659-31F .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
2TL1-5F
Alias/AKA:
MS24659-31F
RoHS:
Yes
HTS:
85365080
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
ON OFF (ON)
Contact Rating @ Voltage:
372.85@(CSA/UL) A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
15/32-32
Body Orientation:
Straight
Terminal Type:
Screw
Dimension:
34.04 x 23.11 x 75.18 mm
Operating Temperature:
-65 to 71 °C
The HONEYWELL part 2TL1-5F is a rugged and versatile MICRO SWITCHâ„¢ Toggle Switch from the TL Series. This specific model features a Double Pole Double Throw (DPDT) configuration with a 3-position (Momentary On - Off - On) design, making it ideal for controlling various electrical circuits. It comes with screw terminals for easy installation and a locking lever that is locked in the extreme position, opposite the keyway. This toggle switch meets military specifications under part number MS24659-31F, ensuring durability and reliability in demanding applications.
Product Highlights:
  • Qualified to MIL-S-3950
  • Environment-proof sealing
  • 1,2, and 4 pole circuitry
  • Standard and pull-to-unlock levers
  • 2 and 3 position, maintained and momentary toggle action
  • Temperature range: -85 F to +160 F
  • Completely sealed switching chamber
  • Step-design case provides added space between terminals to help prevent shorting
  • UL recognized, CSA certified
  • CE approved
Potential Applications:
<ul><li>Industrial machinery and equipment</li><li>Military and commercial aviation</li><li>Construction equipment</li><li>Test instruments</li><li>Agricultural machinery</li><li>Process control</li><li>Medical instrumentation</li></ul>
Search Keywords:
2TL15F
IN STOCK: 55
Can Ship immediately
MOQ for out of Stock Qty:
13
Factory Lead-Time
20 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$81.11
$81.11
5
$80.31
$401.55
10
$76.76
$767.60
13
$76.39
$993.07
25
$76.20
$1,905.00
38
$76.01
$2,888.38
50 +
$74.12
$3,706.00
