BZ-2R by honeywell
Image is representational - see mfr. specs
DATA SHEET

BZ-2R

Honeywell

MICRO SWITCH™ Premium Large Basic Switches: BZ Series, Single Pole Double Throw (SPDT), 15 A 125/250 Vac, ENEC 16 A 250 Vac, Pin Plunger, Solder Termination, Mounting Holes will Accept Pins or Screws, UL, CE, CSA, ENEC .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
BZ-2R
RoHS:
Yes
HTS:
85365080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Pin Plunger
Contact Rating @ Voltage:
186.42 A
Maximum Movement Differential:
0.05 mm
Operating Force:
3.61 N
Termination Style:
Solder
Dimension:
49.28 x 17.45 x 22.61 mm
Body Orientation:
Straight
IP Rating:
N/A
<p>The Honeywell BZ-2R Snap Action Switch is used for simple or precision on/off application needs. A Snap Action Switch is a type of momentary contact micro switch which operates at a rapid speed as it takes very little force or stimulus to operate. This SPDT snap switch is widely used in irrigation systems, timing devices, office equipment, medical and dental equipment, semi-trailer trucks, manually operated devices, and valves.</p> <p>The BZ-2R Snap Action Switch from Honeywell comes with low operating force and differential travel for reliable functionality. Featuring a choice of actuation, termination and operating characteristics, this Honeywell switch is ideal for a variety of industrial and mechanical applications. The elongated mounting hole in this snap action switch enables easier and more accurate mounting. This standard basic switch has a long mechanical life of up to 20,000,000 cycles with 95% survival rate.</p>
Product Highlights:
  • Elongated mounting hole for easier, more accurate mounting
  • Current rating ranges from 15 A to 25 A
  • Accepted world-wide standard "Large Basic" switch
  • Long mechanical life up to 20,000,000 cycles at 95% survival
  • Choice of actuation, termination and operating characteristics
  • Low operating force and differential travel
Potential Applications:
<ul><li>Irrigation systems</li><li>Semi-trailer trucks</li><li>Timing devices</li><li>Office equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li></ul>
Search Keywords:
BZ2R
IN STOCK: 478
Ships today, if you order in
Minimum Order Quantity:
5
Factory Lead-Time
13 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$13.50
$67.50
25
$11.93
$298.25
50
$11.16
$558.00
100
$11.10
$1,110.00
250
$11.00
$2,750.00
500
$10.85
$5,425.00
1,000 +
$10.79
$10,790.00
