V7-2B17D8-022
HoneywellMICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 11 A 125, 250, or 277 Vac, 35,6 mm [1.4 in] Straight Lever Actuator, 41 g [1.45 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 4,75 mm x 0,51 mm [0.187 in x 0.02 in] Quick Connect Termination, UL, CSA .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Honeywell
Part No:
V7-2B17D8-022
RoHS:
Yes
HTS:
85365000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack
1
Package Type:
Tray
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Steel/Straight Lever
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
0.69 mm
Operating Force:
0.4 N
Termination Style:
Quick Connect
Dimension:
28.83 x 10.16 x 26.21 mm
Body Orientation:
Straight
IP Rating:
N/A
<p>The Honeywell V7-2B17D8-022 Snap Action Switch is suitable for simple precision on/off, presence/absence, pressure, temperature and manual operator applications. This Honeywell Switch is designed for 100K operations at a full-load and is best suited for higher cost-of-failure applications. Featuring UL/CSA and ENEC approvals, it comes with world-wide acceptance. </p>
<p>Snap action switches are highly sensitive switches that respond to very small movements and can rapidly change from one contact position to the other. These Honeywell Snap Action Switches are mostly used in appliances, vending machines, timing devices, office equipment, computer/business equipment, test instruments, medical/dental equipment, HVAC equipment, manually operated devices, valves and gaming equipment, etc.</p>
Product Highlights:
- Current rating ranges from 0.1 A to 25 A
- UL/CSA and ENEC approvals
- Best suited for higher cost-of-failure applications
- Designed for 100K operations at a full load or 10M for mechanical life
- World-wide package size acceptance
Potential Applications:
<ul><li>Appliances</li><li>Vending machines</li><li>Timing devices</li><li>Office equipment</li><li>Computer/business equipment</li><li>Test instruments</li><li>Medical/dental equipment</li><li>Communications equipment</li><li>HVAC equipment</li><li>Manually operated devices</li><li>Valves</li><li>Gaming equipment</li><li>Pressure switches</li></ul>Search Keywords:
V72B17D8022
IN STOCK:
8,134
Can Ship immediately
Minimum Order Quantity:
5
Factory Lead-Time
10 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$4.35
$21.75
50
$2.49
$124.50
100
$2.36
$236.00
250
$2.30
$575.00
500
$2.26
$1,130.00
1,000
$2.25
$2,250.00
2,500
$2.24
$5,600.00
5,000
+
$2.23
$11,150.00
Click for Quote
