DBMN-25S-N-A197 by itt cannon
Image is representational - see manufacturer specifications
DATA SHEET

DBMN-25S-N-A197

ITT CANNON

D Subminiature Connector - 25 Contact - Female - 0.109 inch Pitch - Solder Terminal - #4-40 - Receptacle .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DBMN-25S-N-A197
Alias/AKA:
053513-3244
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
B
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C
The ITT CANNON DBMN-25S-N-A197 is a high-quality D subminiature connector designed for reliable and secure connections. With 25 contacts and a female receptacle configuration, it is ideal for a wide range of applications. The connector features a 0.109-inch pitch and solder terminals, ensuring efficient and durable connections. It also has #4-40 screws for convenient and secure mounting. Trust ITT CANNON for superior performance and long-lasting durability with the DBMN-25S-N-A197 D subminiature connector.
Search Keywords:
DBMN25SNA197
IN STOCK: 54
Can Ship immediately
On Order:
125   can ship 3/4/27
Factory Lead-Time
18 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$38.82
$38.82
5
$37.54
$187.70
10
$31.61
$316.10
25
$31.38
$784.50
50
$31.22
$1,561.00
100
$26.54
$2,654.00
250 +
$24.88
$6,220.00
