DR-75-48

MEAN WELL

AC-DC Industrial DIN rail power supply; Output 48Vdc at 1.6A; metal case .. see full description

RoHS Compliant

Packaging

Discontinued & Replaced

Accessories

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

DR-75-48

RoHS:

Yes

HTS:

8504409510

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

AC Input Voltage:

110,230 V

Family:

DR-75

Dimension:

100 x 55.5 x 125.2mm

Efficiency:

81(Typ) %

DC Input Voltage:

N/A

Life Cycle:

Discontinued & Replaced

The DR-75-48 is a 76.8W Industrial DIN Rail Power Supply featuring Constant voltage mode output for single channel. DR-75-48 input voltage ranges from 85 to 264VAC. Voltage output is 48VDC and adjustable from 48 to 53V and current output is adjustable from 0 to 1.6 A with rated current 1.6A. Thanks to the high efficiency up to 81%, it is able of operating from -10 to +60 ℃ case temperature under free air convection. DR-75-48 uses a LED indicator for power on with fixed switching frequency at 50KHz. The DR-75-48 has a 3 years factory warranty.
