Image is representational - see manufacturer specifications

DATA SHEET

HLN-40H-24AB

Name: HLN-40H-24AB
Brand: Mean Well
SKU: 45025460
Price: 50.88 USD
Availability: InStock

MEAN WELL

AC/DC LED Pwr Sply - Const Curr/Volt - 40.1W - Adj/Dim:24 Vdc @ 1,670mA - Dim: 1-10Vdc/PWM/Resist

RoHS Compliant

Packaging

Accessories

Discontinued & Replaced

Accessories

Certificate of Compliance Guarantee

SPECS
FULL DESCRIPTION

Product Attribute

Attribute Value Select Attribute

Products found: 0Show Similar

Supplier:

MEAN WELL

Part No:

HLN-40H-24AB

RoHS:

Yes

HTS:

8504409510

COO:

ECCN:

EAR99

Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

Input/Output Type:

AC/DC8097

Style:

Enclosed

Type:

Constant Current/Voltage

Output Type:

Adjustable,Dimmable

Dimming:

1 to 10 Vdc/PWM/Resistance

Maximum Output Power:

40 W

Output Voltage Range:

14.4 to 24.0 Vdc

Maximum Output Current:

1,670 mA (1.67 A)

Minimum AC Input Voltage:

Maximum AC Input Voltage:

305

Minimum DC Input Voltage:

127

Maximum DC Input Voltage:

431

Termination Style:

Wire Leads

Input Connector Type:

Stripped and Tinned

Output Connector Type:

Stripped and Tinned

Operating Temperature:

-40 to 50 °C

Safety Agency Approvals:

CB, CE, cRUus, EAC, PSE, TUV

NEC Class:

IEC Class:

None

SELV:

Yes

LPS:

Warranty:

3 Years

Family:

HLN-40H

Life Cycle:

Discontinued & Replaced

AC/DC LED Pwr Sply - Const Curr/Volt - 40.1W - Adj/Dim:24 Vdc @ 1,670mA - Dim: 1-10Vdc/PWM/Resist

Product Highlights:

Potential Applications:

Search Keywords:

HLN40H24AB

This product is not in stock and cannot be back-ordered

This product is discontinued, but still in stock

This product is not in stock and cannot be back-ordered

Different packaging options available. See Alternatives

Possible Replacement options available. See Alternatives

This product is NOT RoHS Compliant. See Alternatives

End of Life: Final orders must be placed by 06/30/2026

IN STOCK: 78

Can Ship immediately

BONDED Quantity:

Manufacturer Stock:

0 can ship

On Order:

Stock lot only:

MOQ for out of Stock Qty:

Multiple:

This product is no longer being manufactured but there may be alternatives. We can help you, Contact Us.

VIEW PRODUCT

Min quantity should be greater than or equal () in order to activate the custom price. Otherwise you will get the normal price.

Price (USD)

A tariff of {0} may be applied if shipping to the United States.

Quantity

Unit Price

Ext. Price

$50.88

$50.11

$250.55

$49.36

$493.60

$48.62

$1,215.50

50 +

$29.92

$1,496.00

Click for Quote

Schedule Order

You may schedule release quantities and ship dates in the shopping cart.

RECOMMENDED REPLACEMENT

LPF-40-24

VIEW PRODUCT

Product Guides

Datasheet
