LRS-350-48

Name: LRS-350-48
Brand: Mean Well
SKU: 47466835
Availability: InStock

MEAN WELL

AC-DC Single output enclosed power supply; Universal AC input; Output 48Vdc at 7.3A; Up to 5G vibration; 1U low profile .. see full description

RoHS Compliant

Packaging

Accessories

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

LRS-350-48

RoHS:

Yes

HTS:

8504409510

COO:

ECCN:

EAR99

Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

DC Input Voltage:

240 to 370 V

Dimension:

215 x 115 x 30 mm

AC Input Voltage:

90 to 132,180 to 264 V

The LRS-350-48 is a 305.4W single-output enclosed type power supply with 30mm of low profile design. Adopting the input of 114VAC or 230VAC (select by switch), the LRS-350-48 provides an output voltage line of 48V . In addition to the high efficiency 89%,with built-in long life fan LRS-350-48 can work under -25℃ through 70 ℃ under air convection with full load. Delivering an extremly low no load power consumption ( <.75 W), it allows the end system to easily meet the worldwide energy requirement.LRS-350-48 has the complete protection functions and 5G anti-vibration capability; it is complied with international safety regulations such as UL60950-1. LRS-350-48 serves as high price-to performance power supply solution for various industrial applications.
