SDR-240-48

Name: SDR-240-48
Brand: Mean Well
SKU: 37810173
Price: 93.89 USD
Availability: InStock

MEAN WELL

AC-DC Industrial DIN rail power supply; Output 48Vdc at 5A; Metal casing; Ultra slim width 63mm .. see full description

RoHS Compliant

Packaging

Accessories

Certificate of Compliance Guarantee

Product Attribute

Attribute Value Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

SDR-240-48

RoHS:

Yes

HTS:

8504409530

COO:

ECCN:

EAR99

Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

AC Input Voltage:

88 to 264 V

DC Input Voltage:

124 to 370 V

Efficiency:

94(Typ) %

Family:

SDR-240

Dimension:

63 x 113.5 x 125.2mm

The SDR-240-48 is a 240W Industrial DIN Rail Power Supply featuring Constant voltage mode output for single channel. SDR-240-48 input voltage ranges from 88 to 264VAC. Voltage output is 48VDC and adjustable from 48 to 55V and current output is adjustable from 0 to 5 A with rated current 5A. Thanks to the high efficiency up to 94%, it is able of operating from -25 to +70 ℃ case temperature under free air convection. SDR-240-48 uses built-in active PFC function with power factor PF>.93. The SDR-240-48 has a 3 years factory warranty.
