MCP23008-E/SO by microchip technology
Image is representational - see mfr. specs
DATA SHEET

MCP23008-E/SO

Microchip Technology

I/O Expander - 8bit - 1.7 MHz - I2C - 1.8 to 5.5 V - SOIC W 18-Pin. .. see full description

RoHS Compliant
TUBE Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP23008-E/SO
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
42
Package Type:
TUBE
Maximum Operating Supply Voltage:
5.5 V
Manual Reset:
Yes
Family:
MCP23008
Interrupt Output:
Yes
I2C Bus Interface Mode:
Standard Mode,Fast Mode,Fast Mode Plus
Interface Speed:
1700 kHz
Interface Type:
I²C
Dimension:
11.55 x 7.5 x 2.05(Min) mm
The MCP23008-E/SO is a 8bit I/O expander with high speed I2C interface in 18 lead SOIC package. This I/O expander provides 8bit, general purpose parallel I/O expansion for I2C bus applications. The MCP23008 consists of multiple 8bit configuration registers for input, output and polarity selection. The system master can enable I/Os as either inputs or outputs by writing I/O configuration bits. Data for each input or output is kept in corresponding input or output register. The polarity of input port register can be inverted with polarity inversion register. All registers can be read by system master.
Search Keywords:
MCP23008ESO
  Different packaging options available.  See Alternatives
IN STOCK: 1,174
Can Ship immediately
Minimum Order Quantity:
42
Multiple:
42
Factory Lead-Time
7 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
42
$1.129
$47.418
252
$1.035
$260.820
504
$1.024
$516.096
1,008
$1.019
$1,027.152
2,520
$1.014
$2,555.280
5,040
$1.009
$5,085.360
7,518 +
$1.004
$7,548.072
Suppliers Standard Package
