90136-1105 by molex / waldom
Image is representational - see manufacturer specifications
DATA SHEET

90136-1105

Molex / Waldom

Conn Shrouded Header HDR 5 POS 2.54mm Solder ST Thru-Hole C-Grid III™ Tray

RoHS Compliant
Tray Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Molex / Waldom
Part No:
90136-1105
RoHS:
Yes
HTS:
8536694040
COO:
MY
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Tray
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
5
Maximum Voltage Rating:
350,350 VDC|VAC
Maximum Current Rating:
3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C
Conn Shrouded Header HDR 5 POS 2.54mm Solder ST Thru-Hole C-Grid III™ Tray
Search Keywords:
901361105
IN STOCK: 0
Minimum Order Quantity:
150
Factory Lead-Time
15 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
150
$0.6426
$96.3900
800
$0.6120
$489.6000
1,600
$0.5814
$930.2400
3,200
$0.5406
$1,729.9200
8,000
$0.4784
$3,827.2000
20,000
$0.4661
$9,322.0000
40,000 +
$0.4406
$17,624.0000
Product Guides
PDF Datasheet
