NC3MAV-0
NEUTRIKA Series - 3 pole male XLR receptacle, grounding: ground contact connected to shell ground - but not to front panel and Pin 1 - vertical PCB mount The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smalle .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC3MAV-0
RoHS:
Yes
HTS:
8536694040.00
COO:
LI
ECCN:
EAR99
Supplier Standard Pack
100
Type:
XLR Connector
Gender:
M
Body Orientation:
Straight
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm between centres). Hard gold plated contacts with polished contact areas. UL recognized component.
<br /><br />3 pole male XLR receptacle, grounding: ground contact connected to shell ground, but not to front panel and Pin 1, vertical PCB mount
Product Highlights:
- Smallest XLR receptacles, highest packing density
- Plastic housing
- Polished contact areas and hard gold plating
- Housing flammability UL94V-0
Search Keywords:
NC3MAV0
IN STOCK:
1,100
Ships today, if you order in
Minimum Order Quantity:
100
Multiple:
100
Factory Lead-Time
3 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
100
$1.17
$117.00
300
$1.13
$339.00
500
$1.11
$555.00
1,000
$1.09
$1,090.00
2,500
$1.08
$2,700.00
5,000
$1.06
$5,300.00
7,500
$1.04
$7,800.00
10,000
+
$1.03
$10,300.00
Please Note:
Tariffs may apply for U.S. shipments
Product Guides
Datasheet
