NC3MBH-B by neutrik
Image is representational - see manufacturer specifications
DATA SHEET

NC3MBH-B

NEUTRIK

B Series - 3 pole male XLR receptacle - grounding: separate ground contact to mating connector shell and front panel - steel retention lug - horizontal PCB mount - black chrome shell Same as A series with exception of a metal mounting flange featuring c .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC3MBH-B
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
M
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C
Same as A series with exception of a metal mounting flange featuring continuous circumferential ground contact to chassis for best EMC practice. UL recognized component. <br /><br />3 pole male XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, steel retention lug, horizontal PCB mount, black chrome shell
Product Highlights:
  • Smallest XLR receptacles, highest packing density
  • Metal mounting flange featuring continuous circumferential ground contact to chassis for best EMC and RF protection
  • Housing flammability UL94V-0
Search Keywords:
NC3MBHB
IN STOCK: 693
Can Ship immediately
Minimum Order Quantity:
10
Factory Lead-Time
15 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
10
$7.11
$71.10
50
$4.97
$248.50
100
$4.64
$464.00
300
$4.40
$1,320.00
500
$4.04
$2,020.00
1,000
$3.29
$3,290.00
2,500
$3.07
$7,675.00
5,000 +
$2.64
$13,200.00
Supplier's Standard Package
