NC5FD-LX-B by neutrik
Image is representational - see mfr. specs
DATA SHEET

NC5FD-LX-B

NEUTRIK

DLX Series - 5 pole female receptacle - solder cups - black metal housing - gold contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact - which offers excellent RF protection and shielding. .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC5FD-LX-B
RoHS:
Yes
HTS:
8536694030.00
COO:
LI
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
IP40 XLR Connector
Gender:
F
Body Orientation:
Straight
Mounting:
Panel Mount
Housing Material:
Polyamide 6/6
Number of Contacts:
5
Contact Plating:
Gold Alloy Over Nickel
Termination Method:
Solder Cup
Operating Temperature:
-30 to 80 °C
5 pole female receptacle, solder cups, black metal housing, gold contacts <br /><br />The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector.
Product Highlights:
  • All metal housing offers best overall RF protection and electromagnetic shielding
  • New duplex ground contact for excellent contact integrity between chassis and cable connector
  • Female contact incorporates a solder barrier to prevent solder running into the contact mating area
  • Larger solder contacts for easier termination
  • Optional connection to easily join pin1 to chassis ground
  • D-style housing provides installation compatibility with industry standard D mounting dimensions
Search Keywords:
NC5FDLXB
IN STOCK: 51
Can Ship immediately
Minimum Order Quantity:
5
Factory Lead-Time
3 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$27.47
$137.35
25
$26.94
$673.50
50
$26.80
$1,340.00
100
$26.67
$2,667.00
300
$26.02
$7,806.00
500
$25.38
$12,690.00
1,000 +
$24.52
$24,520.00
Please Note: Tariffs may apply for U.S. shipments
