AQG22224 by panasonic electronic components
Image is representational - see manufacturer specifications
DATA SHEET

AQG22224

Panasonic Electronic Components

Solid State Relay 28.8V DC-IN 2A 264V AC-OUT 4-Pin Slim .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQG22224
RoHS:
Yes
HTS:
8536490080
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Output Type:
AC
Maximum Output Voltage:
264 V
Maximum Output Current:
2 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
28.8 V
Mounting:
Through Hole
Circuit Arrangement:
N/A
Dimension:
24.5(Max) x 4.5(Max) x 20.5(Max) mm
AQG22224 is a slim type solid state relay (SSR) designed for AC load control applications. It features a random switching method with a rated control voltage of 24 V DC (19.2 to 28.8 V DC range), a maximum load current of 2 A, and a load voltage range of 75 to 264 Vrms. The relay offers high dielectric strength of 3,000 Vrms between input and output, a maximum thickness of 4.5 mm, and includes a built-in snubber circuit to prevent malfunction due to noise. With input impedance of approximately 1.6 kO and certifications including C-UL (UL508) and VDE (EN60950-1) reinforced insulation, this SSR is suitable for household appliances, healthcare equipment, industrial machinery, and microcomputer boards.
Search Keywords:
AQG22224
IN STOCK: 100
Can Ship immediately
On Order:
1,000   can ship 3/10/27
Minimum Order Quantity:
20
Multiple:
20
Factory Lead-Time
27 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
20
$4.11
$82.20
60
$3.95
$237.00
100
$3.82
$382.00
260
$3.61
$938.60
500
$3.48
$1,740.00
1,000
$3.36
$3,360.00
2,500
$3.35
$8,375.00
5,000 +
$3.34
$16,700.00
