JW2SN-B-DC24V by panasonic electronic components
Image is representational - see mfr. specs
DATA SHEET

JW2SN-B-DC24V

Panasonic Electronic Components

Power Relay 24VDC 5A DPDT(28.6mm 12.8mm 20mm) THT .. see full description

RoHS Non-Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JW2SN-B-DC24V
RoHS:
No
HTS:
8536410020
COO:
TH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
1.1 KOhm
The PANASONIC EW/AROMAT part JW2SN-B-DC24V is a highly efficient power relay designed for various electronic applications. With a coil voltage of 24VDC, this relay has a switching capacity of 5A, making it suitable for both low and high power loads. Its Double Pole Double Throw (DPDT) configuration allows for versatile control of current flow. Measuring at 28.6mm x 12.8mm x 20mm, this through-hole mounted relay is compact in size, making it ideal for space-constrained designs. Its advanced construction ensures reliable performance and durability, even in harsh environmental conditions. The JW2SN-B-DC24V relay from PANASONIC EW/AROMAT is an excellent choice for industrial, automotive, and consumer electronics applications requiring efficient and reliable power control.
Search Keywords:
JW2SNBDC24V
  This product is NOT RoHS Compliant.  See Alternatives
IN STOCK: 440
Ships today, if you order in
On Order:
2,000   can ship 7/29/26
2,500   can ship 9/10/26
Minimum Order Quantity:
100
Multiple:
100
Factory Lead-Time
24 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
100
$1.81
$181.00
300
$1.72
$516.00
500
$1.71
$855.00
1,000
$1.70
$1,700.00
2,500
$1.69
$4,225.00
5,000
$1.68
$8,400.00
7,500 +
$1.67
$12,525.00
Suppliers Standard Package
