TQ2-9V by panasonic electronic components
Image is representational - see mfr. specs
DATA SHEET

TQ2-9V

Panasonic Electronic Components

Signal Relay 9VDC 1A DPDT(14x9x5)mm THT .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TQ2-9V
RoHS:
Yes
HTS:
8536490075
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
9 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
1 A
Mounting:
Through Hole12526
Operating Temperature:
-40 to 70 °C
Dimension:
14 x 9 x 5 mm
Termination Style:
PC Pin12536
Coil Current:
15.5 mA
Contact Form:
2 Form C12515
The PANASONIC EW/AROMAT part TQ2-9V is a compact and reliable signal relay designed for various electronic applications. With a coil voltage of 9VDC and a contact rating of 1A, this DPDT (Double Pole Double Throw) relay is capable of efficiently switching or routing signals in electronic circuits. Its compact dimensions of 14x9x5mm make it suitable for space-constrained applications. The Through-Hole Technology (THT) allows for easy installation and secure soldering onto PCBs. Trust the PANASONIC EW/AROMAT TQ2-9V relay for its exceptional quality and performance for your signal switching needs.
Search Keywords:
TQ29V
IN STOCK: 7,826
Can Ship immediately
Minimum Order Quantity:
50
Multiple:
50
Factory Lead-Time
16 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
50
$1.41
$70.50
100
$1.36
$136.00
250
$1.29
$322.50
500
$1.23
$615.00
1,000
$1.19
$1,190.00
2,500
$1.18
$2,950.00
5,000
$1.10
$5,500.00
7,500 +
$1.09
$8,175.00
Suppliers Standard Package
