TX2SA-5V-Z by panasonic electronic components
Image is representational - see manufacturer specifications
DATA SHEET

TX2SA-5V-Z

Panasonic Electronic Components

Signal Relay 5VDC 2A DPDT(15x9.4x8.4)mm SMD Medical .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TX2SA-5V-Z
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
500
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Surface Mount12526
Operating Temperature:
-40 to 85 °C
Dimension:
15 x 9.4 x 8.2 mm
Termination Style:
Gull Wing12536
Coil Current:
28.1 mA
Contact Form:
2 Form C12515
The PANASONIC EW/AROMAT TX2SA-5V-Z is a compact, high-performance signal relay designed for medical applications. With a voltage rating of 5VDC and a current rating of 2A, this DPDT relay is ideal for electronic devices that require reliable signal switching. Its small size (15x9.4x8.4mm) and surface mount design make it easy to integrate into compact medical equipment. The PANASONIC EW/AROMAT TX2SA-5V-Z is crafted using high-quality materials, ensuring long-lasting performance and exceptional durability. Trust this reliable signal relay to provide precise and efficient signal control in your medical devices.
Search Keywords:
TX2SA5VZ
  Different packaging options available.  See Alternatives
  Possible Replacement options available.  See Alternatives
IN STOCK: 9,243
Ships today, if you order in
Minimum Order Quantity:
5
Factory Lead-Time
52 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$4.22
$21.10
25
$3.80
$95.00
50
$2.93
$146.50
100
$2.59
$259.00
250
$2.44
$610.00
500
$2.33
$1,165.00
1,000 +
$1.98
$1,980.00
Supplier's Standard Package
