ERZ-V20R431 by panasonic
Image is representational - see manufacturer specifications
DATA SHEET

ERZ-V20R431

Panasonic

The ERZ-V20R431 is a radial leaded ZNR transient/surge absorber designed for overvoltage protection in electronic circuits. .. see full description

RoHS Compliant
Packaging
Accessories
End of Life: Final orders must be placed by 03/31/2027
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
ERZ-V20R431
RoHS:
Yes
HTS:
8533404000
COO:
ID
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Varistor Voltage:
430 V
Clamping Voltage:
710 V
Clamping Current:
100 A
Mounting:
Through Hole
Dimension:
6.4 x 24.5 x 21.5 mm
Maximum AC Voltage Rating:
275 V
Maximum DC Voltage Rating:
350 V
Maximum Surge Current:
10000 A
Lead Style:
Radial
Lead Pitch:
10 mm
Tolerance Voltage:
N/A
End of Life:
Final orders must be placed by 03/31/2027
The ERZ-V20R431 is a V series ZNR transient/surge absorber engineered to protect against transient overvoltages. It has a nominal varistor voltage of 430V and a maximum allowable voltage of 275V ACrms or 350V DC. This device features a maximum clamping voltage of 710V at a peak current of 100A and can handle a maximum peak surge current of 10,000A (8/20 µs, 1 time). It offers a high energy handling capability of 303J (10/1000 µs) and operates within a temperature range of -40°C to 85°C. The ERZ-V20R431 is well-suited for surge protection in AC 100V to 220V line-to-line and line-to-ground applications.
Search Keywords:
ERZV20R431
  End of Life: Final orders must be placed by 03/31/2027
IN STOCK: 1,205
Can Ship immediately
On Order:
1,000   can ship 12/17/26
MOQ for In Stock Qty:
25
MOQ for out of Stock Qty:
250
Factory Lead-Time
24 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
25
$2.828
$70.700
50
$2.820
$141.000
100
$2.814
$281.400
250
$2.806
$701.500
500
$2.104
$1,052.000
750
$1.964
$1,473.000
1,000 +
$1.926
$1,926.000
Supplier's Standard Package
Product Guides
PDF Datasheet
