Supplier:
Phoenix Contact
Part No:
1648306
RoHS:
Yes
HTS:
8536694030
COO:
CN
ECCN:
EAR99
Supplier's Standard Package
1
Type:
Rectangular
Mounting:
Panel Mount
Body Orientation:
Straight
Gender:
PL
Pitch:
N/A
Termination Method:
Screw
Number of Contacts:
24
Maximum Voltage Rating:
500 V
Maximum Current Rating:
16 A
Operating Temperature:
-40 to 125 °C
1648306 is a 24-position, HEAVYCON B24 series female insert. This screw connected pin insert has once connections per position and 24+PE positions. Conductor cross section is 14 to 20 AWG.
Search Keywords:
1648306
IN STOCK:
55
Can Ship immediately
Factory Lead-Time
12 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$29.62
$29.62
5
+
$28.14
$140.70
Product Guides
Datasheet
Accessories
HC-B-PES
PE screw - for contact inserts HC-B / HC-BB / HC-DD / HC-D40 / HC-D64
HC-B-ZG
Strain relief clamps contact inserts of series: B- - BB- - D 40 - D 64 - DD and HV - strai ...
HC-B-3PE
PE multiplier - for three PE connections - for HC-B (besides HC-B..E..ZZ) / HC-BB / HC-DD ...
HC-B-ZS
Strain relief clamps contact inserts of series: B- - BB- - D 40 - D 64 - DD and HV - later ...
HC-CBU
Coding socket for coding up to 16 connectors
CP-HC
Coding profile - 4 coding profiles per strip - for insertion in coding keyways
HC-CB
Coding pin - prevents mismating of up to six connectors with an identical number of positi ...
HC-CST
Coding peg for coding up to 16 connectors
HC-B-24-ANDOCK
Docking frame for racks - for contact inserts of B24 type - with four M5 flat headed screw ...
