DATA SHEET

1759075

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 8 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.5 mm .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1759075
Alias/AKA:
MSTB-2-5/-8-G-5-08
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
8
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT part 1759075 is a high-quality PCB header designed for reliable electrical connections. With a nominal current of 12 A and a rated voltage of 320 V (III/2), this header is suitable for various electronic applications. The nominal cross-section of 2.5 mm² allows for efficient power transmission, while the 8 positions and 5.08 mm pitch provide ample space for connections. The header is constructed in a sleek green color with a tin contact surface for enhanced conductivity. This component is ideal for use with wave soldering mounting techniques and features a linear pinning layout with a solder pin length of 3.5 mm. Trust PHOENIX CONTACT part 1759075 for your PCB header needs.
Search Keywords:
1759075
IN STOCK: 643
Ships today, if you order in
Minimum Order Quantity:
10
Factory Lead-Time
5 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
10
$2.42
$24.20
100
$1.95
$195.00
300
$1.91
$573.00
500
$1.90
$950.00
1,000
$1.89
$1,890.00
2,500
$1.88
$4,700.00
5,000
$1.87
$9,350.00
7,500 +
$1.86
$13,950.00
Supplier's Standard Package
