1777109 by phoenix contact
Image is representational - see manufacturer specifications
DATA SHEET

1777109

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 5 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777109
Alias/AKA:
MSTBV-2-5/-5-GF-5-08
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
5
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT part 1777109 is a PCB header designed for reliable electrical connections. It features a nominal current of 12 A and a rated voltage (III/2) of 320 V, making it suitable for a variety of applications. The nominal cross-section is 2.5 mm², with 5 positions and a pitch of 5.08 mm. The headers are colored green and have a contact surface coated with tin for improved conductivity. They are designed for wave soldering mounting and have a linear pinning layout with solder pins measuring 3.9 mm in length.
Search Keywords:
1777109
IN STOCK: 83
Ships today, if you order in
On Order:
250   can ship 3/8/27
Minimum Order Quantity:
10
Factory Lead-Time
31 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
10
$4.47
$44.70
50
$3.72
$186.00
100
$3.71
$371.00
250
$3.37
$842.50
500
$3.28
$1,640.00
1,000
$3.27
$3,270.00
2,500
$3.15
$7,875.00
5,000 +
$3.11
$15,550.00
