1777545
Phoenix ContactPCB terminal block - nominal current: 41 A - rated voltage (III/2): 1000 V - nominal cross section: 4 mm² - pitch: 6.35 mm - number of positions: 2 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Zigzag pinning W - Solder pin [P]: 5 mm .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777545
Alias/AKA:
MKDS-5N-HV/-2-ZB-6-35
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack
50
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
6.35 mm
Number of Circuits:
2
Maximum Voltage Rating:
1000 V
Maximum Current Rating:
41 A
Wire Size:
10-24 AWG
Operating Temperature:
-40(Min) °C
PCB terminal block - nominal current: 41 A - rated voltage (III/2): 1000 V - nominal cross section: 4 mm² - pitch: 6.35 mm - number of positions: 2 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Zigzag pinning W - Solder pin [P]: 5 mm
Search Keywords:
1777545
IN STOCK:
0
On Order:
250
can ship 5/22/26
Minimum Order Quantity:
50
Multiple:
50
Factory Lead-Time
8 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
50
$2.15
$107.50
100
$2.03
$203.00
250
$1.92
$480.00
500
$1.85
$925.00
1,000
$1.80
$1,800.00
2,500
$1.76
$4,400.00
5,000
$1.73
$8,650.00
7,500
+
$1.71
$12,825.00
Please Note:
Tariffs may apply for U.S. shipments
Product Guides
Datasheet
