H1102NLT by pulse electronics
Image is representational - see manufacturer specifications
DATA SHEET

H1102NLT

Pulse Electronics

MDL,SIN,100D,1:1,SMT,TR, NPB

RoHS Compliant
REEL Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Pulse Electronics
Part No:
H1102NLT
RoHS:
Yes
HTS:
8504312000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
600
Package Type:
REEL
Maximum DCR Primary Side:
0.65 Ohm
Maximum DCR Secondary Side:
0.65 Ohm
Dimension:
12.7mm x 9.65mm x 5.99 mm
Lead Style:
Gull Wing
Family:
H1102
The Pulse Electronics H1102NLT is an Audio/Signal transformer with a turns ratios of TX (1:1)/ RX (1:1). It is a SMD device which has 1 Port and 16 terminals. It is used in the most space-restrictive applications.
Search Keywords:
H1102NLT
  Possible Replacement options available.  See Alternatives
IN STOCK: 1,685
Ships today, if you order in
On Order:
1,200   can ship 3/1/27
Minimum Order Quantity:
100
Factory Lead-Time
19 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
100
$1.86
$186.00
250
$1.82
$455.00
600
$1.79
$1,074.00
1,200
$1.78
$2,136.00
3,000
$1.77
$5,310.00
5,400
$1.76
$9,504.00
7,800
$1.75
$13,650.00
10,200 +
$1.74
$17,748.00
Supplier's Standard Package
Product Guides
PDF Datasheet
