CMA-6542PF by same sky
Image is representational - see mfr. specs
DATA SHEET

CMA-6542PF

Same Sky

9.7 mm - Omnidirectional - PCB Mount - 4.5 Vdc - Electret Condenser Microphone .. see full description

RoHS Compliant
Box Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Same Sky
Part No:
CMA-6542PF
RoHS:
Yes
HTS:
8518108030
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Box
Diameter:
0.38 in
Dimension:
6.5 x 9.7mm
Directivity:
Omnidirectional
Family:
CMA-6542PF
Depth:
0.26 in
Maximum Current Consumption:
0.5 mA
Frequency Range:
50 to 20000 Hz
Maximum Impedance:
2200 Ohm
The CMA-6542PF is an omnidirectional electret condenser microphone designed for general audio capture. It features a typical sensitivity of -42 dB and operates over a frequency range of 50 to 20,000 Hz. This microphone requires a typical operating voltage of 4.5 Vdc, has a maximum current consumption of 0.5 mA, and provides a minimum signal-to-noise ratio of 60 dBA. Housed in a compact Ø9.7 x 6.5 mm aluminum case, its robust design and wide operating temperature range of -20°C to 70°C make it suitable for various audio recording applications.
Search Keywords:
CMA6542PF
IN STOCK: 12,941
Ships today, if you order in
Minimum Order Quantity:
50
Factory Lead-Time
11 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
50
$0.5770
$28.8500
250
$0.5295
$132.3750
1,000
$0.4885
$488.5000
3,000
$0.4561
$1,368.3000
5,000
$0.4410
$2,205.0000
8,000
$0.4271
$3,416.8000
10,000
$0.4205
$4,205.0000
15,000 +
$0.4086
$6,129.0000
Please Note: Tariffs may apply for U.S. shipments
