SMA-J-P-H-ST-TH1 by samtec
Image is representational - see manufacturer specifications
DATA SHEET

SMA-J-P-H-ST-TH1

Samtec

RF / Coaxial Connector - SMA Coaxial - Straight Jack - Through Hole Vertical - 50 ohm - 7 x 7 x 9.52 mm.

RoHS Compliant
Tray Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
SMA-J-P-H-ST-TH1
RoHS:
Yes
HTS:
8536694010
COO:
TW
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Tray
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 20 Hz to GHz
Gender:
F
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 125 °C
Dimension:
7 x 7 x 9.52 mm
The SMA-J-P-H-ST-TH1 is coaxial connector with gold-plated beryllium copper contacts and PTFE insulator. This connector has a brass shell, PCB mounting and straight orientation. Temperature range from -65°C to 125°C.
Search Keywords:
SMAJPHSTTH1
IN STOCK: 0
On Order:
2,500   can ship 8/10/26
2,500   can ship 7/19/27
Minimum Order Quantity:
10
Factory Lead-Time
51 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
10
$3.25
$32.50
50
$2.96
$148.00
250
$2.75
$687.50
500
$2.43
$1,215.00
1,000
$2.23
$2,230.00
2,500 +
$1.97
$4,925.00
