389FXBXC-24D by schneider electric-legacy relays
Image is representational - see manufacturer specifications
DATA SHEET

389FXBXC-24D

Schneider Electric-Legacy Relays

Power relay - SE Relays - DPDT - 25A - 24 VDC - plug-in socket cover .. see full description

RoHS Compliant
Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
389FXBXC-24D
Alias/AKA:
W389FXBXC-24D
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
25 A
Mounting:
Socket
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 55 °C
The Magnecraft / Schneider Electric part 389FXBXC-24D is an electromechanical relay designed for various power applications. It operates on a 24VDC input and offers a 400Ohm coil resistance. With a double pole double throw (DPDT) configuration, it facilitates versatile switching and control functions. This high-quality relay is capable of handling 13ADC and 25AAC current. The compact dimensions of 35.72x38.89mm make it suitable for space-constrained installations. It also comes with a socket for easy integration into existing systems. The Magnecraft / Schneider Electric 389FXBXC-24D is a reliable and efficient solution for power relay requirements.
Search Keywords:
389FXBXC24D
IN STOCK: 433
Can Ship immediately
Minimum Order Quantity:
10
Multiple:
10
Factory Lead-Time
9 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
10
$43.14
$431.40
30
$41.24
$1,237.20
50
$40.34
$2,017.00
100
$39.14
$3,914.00
250
$37.54
$9,385.00
500
$36.34
$18,170.00
1,000 +
$35.82
$35,820.00
