ADP0204 is a DIP switch assembly designed for reliable switching and control applications. The device features gold-plated copper alloy moving and fixed contacts with a maximum contact resistance of 50 milliohms, ensuring low-loss signal transmission. It is rated for a maximum switching current of 100 milliamps at 24V DC and a maximum non-switching current of 1 ampere at 5V DC, with an insulation resistance of 100 megohms minimum at 100 VDC. The switch is constructed with a PPS 94V-O black case and cover, a white nylon PA6T 94V-O actuator, and is designed to withstand 1000 cycles minimum with an actuation force of 800 grams maximum. Operating over a temperature range of -30°C to +85°C and featuring a dielectric strength of 500 VAC, the ADP0204 is suitable for industrial control panels, consumer electronics, and instrumentation where reliable switching and compact form factor are required.
