1059684-1
TE Connectivity / AMP BrandOSP, Mini Connector Plug, Male Pin 50 Ohm Through Hole Solder .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1059684-1
Alias/AKA:
4563-0000-00
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack
1
Package Type:
Bag
Type:
OSP Miniature Modular
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
PL
Mounting:
Through Hole
Body Orientation:
Straight
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 125 °C
Dimension:
6.35 x 6.35 x 8.71 mm
The 1059684-1 is a RF / Coaxial Connector, OSP Coaxial, Straight Plug, Solder, 50 ohm, Beryllium Copper. Shield Termination Solder
Impedance 50 Ohm
Mounting Type Through Hole
Mounting Feature -
Cable Group -
Fastening Type Snap-On
Frequency - Max 18GHz
Number of Ports 1
Housing Color Gold
Body Material Stainless Steel
Body Finish Gold
Center Contact Plating Gold
Dielectric Material Polytetrafluoroethylene (PTFE)
Operating Temperature -65°C ~ 125°C
Center Contact Material Beryllium Copper
Voltage Rating 500V
Mating Cycles 5000
Product Highlights:
- Connector
- OSP Miniature Modular Product Line
- Terminate To Printed Circuit Board
- Plug
- Not Sealed
Search Keywords:
10596841
IN STOCK:
590
Can Ship immediately
Factory Lead-Time
20 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$49.08
$49.08
5
$46.26
$231.30
10
$45.56
$455.60
25
$44.58
$1,114.50
50
$43.69
$2,184.50
100
$43.13
$4,313.00
250
+
$42.87
$10,717.50
Product Guides
Product Drawing - OSP STRAIGHT PCB PLUG
Datasheet
Product Changes
PCN - 01-Sep-2014 - Manufacturing Location Change
