1393114-1 by te connectivity / amp brand
Image is representational - see mfr. specs
DATA SHEET

1393114-1

TE Connectivity / AMP Brand

General Purpose Relay SPST-NO (DM) (1 Form X) 24VDC Coil Socketable .. see full description

RoHS Compliant
Pack Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1393114-1
Alias/AKA:
KUEP-3D15-24
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO-DM
Maximum Current Rating:
10 A
Mounting:
Plain Case
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
472 Ohm
The 1393114-1 is a general-purpose Panel Plug-in Relay with 24VDC coil. This relay has 1 form-X (1NO-DM) AgCdO contact. 4.75mm (0.187 inch) quick-connect terminal, socket mount with plain case. Class B coil insulation. Contact Voltage VDC: 150VDC Contact Material: Silver Cadmium Oxide Coil Resistance: 472ohm Enclosed relay with magnetic blow-outs -45 to 70°C Operating temperature range RT I Environmental protection rating Applications Industrial
Product Highlights:
  • KUEP Series
  • Contact Arrangement = 1 Form X, SPST-NO-DM, 1 N/O Bridge Contact
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode
Search Keywords:
13931141
IN STOCK: 0
On Order:
1,038   can ship 9/21/26
1,050   can ship 10/5/26
Factory Lead-Time
25 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$43.39
$43.39
5
$40.06
$200.30
10
$38.14
$381.40
25
$35.09
$877.25
50
$34.16
$1,708.00
100
$33.84
$3,384.00
250 +
$32.36
$8,090.00
Suppliers Standard Package
