1658613-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
DATA SHEET

1658613-1

TE Connectivity / AMP Brand

D Sub Connector - DB37 - 37 Contacts - Plug - IDC / IDT - DC - Amplimite HDF-20 Series - Metal Body. .. see full description

RoHS Compliant
TUBE Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658613-1
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
40
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
Pin
Termination Method:
IDT
Shell Size:
4
Number of Contacts:
37
Contact Plating:
Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:
-55 to 105 °C
The 1658613-1 is a 37-way 2-row IDC Standard D-sub Plug for flat ribbon cable. It has phosphor bronze contacts and standard mounting holes. This Amplimite HDF-20 series low profile connector comes with tin-plated steel shell, thermoplastic housing and tin over nickel plated solder tail. It accepts 28 to 26AWG wire.
Product Highlights:
  • Connector
  • Product Series = HDF-20 (Ribbon Cable)
  • Number of Positions = 37
  • Plug
  • With Contacts
Search Keywords:
16586131
IN STOCK: 16
Ships today, if you order in
Minimum Order Quantity:
5
Factory Lead-Time
31 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
5
$12.28
$61.40
40
$12.02
$480.80
80
$11.79
$943.20
120
$11.67
$1,400.40
280
$11.44
$3,203.20
520
$10.80
$5,616.00
1,000 +
$9.96
$9,960.00
