1658691-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
DATA SHEET

1658691-1

TE Connectivity / AMP Brand

D Sub Connector Housing - 15 Positions - D Sub - 1 - AMPLIMITE HDP-22 Series - Plug - Steel Body. .. see full description

RoHS Compliant
BOX Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1658691-1
RoHS:
Yes
HTS:
8538908180
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
400
Package Type:
BOX
Type:
High Density D-Sub
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
Pin
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
15
Contact Plating:
N/A
Operating Temperature:
N/A
Using the high density d-sub 1658691-1 DVI connector from TE Connectivity is fast and easy for communicating between serial connections in your circuit. It has a straight body orientation. This 3-row connector has a single port. 1658691-1 is housed in nylon. Its 15 terminals use the crimp termination method. This product is 30.81 mm long, 12.55 mm tall and 18.21 mm deep.
Product Highlights:
  • Product Series = HDP-22 (Crimp Snap)
  • 15 Positions
  • Without Enclosure
  • Housing Gender = Plug
  • Without Contacts
Search Keywords:
16586911
IN STOCK: 1
Can Ship immediately
Buy all 1 in-stock or the regular minimum order quantity of 5
Stock lot only:
1
Minimum Order Quantity:
5
Factory Lead-Time
18 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$11.473
$11.473
5
$10.430
$52.150
25
$9.360
$234.000
50
$8.730
$436.500
100
$8.080
$808.000
400
$7.980
$3,192.000
800
$7.960
$6,368.000
1,200 +
$7.940
$9,528.000
