1-745491-9 by te connectivity / amp brand
Image is representational - see manufacturer specifications
DATA SHEET

1-745491-9

TE Connectivity / AMP Brand

RCPT ASSY,9P,HDE,MS .. see full description

RoHS Compliant
TRAY Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-745491-9
RoHS:
Yes
HTS:
8536698000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
55
Package Type:
TRAY
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
Crimp
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C
1-745491-9 is an AMPLIMITE HDE-20 series D-subminiature receptacle connector designed for reliable cable termination applications. This connector features 9 contact positions in a shell size 1 configuration with dimensions of 1.213 inches (Dim. A) and 0.984 inches (Dim. B), and is preloaded with insulation displacement socket contacts for 26-22 AWG wire. The connector utilizes a 94V-0 rated thermoplastic insert in black and accepts wire with a maximum insulation thickness of 0.015 inches and maximum insulation diameter of 0.060 inches. It is designed for terminating solid or stranded wire (7 strand max) with individual conductor strands larger than 0.005 inch diameter. Common applications include industrial machinery, medical instrumentation, computers and peripherals, and data storage systems where reliable D-subminiature connections are required.
Product Highlights:
  • Connector
  • Product Series = HDE-20 (IDC)
  • Number of Positions = 9
  • Receptacle
  • With Contacts
Search Keywords:
17454919
IN STOCK: 46
Ships today, if you order in
Buy all 46 in-stock or the regular minimum order quantity of 55
Stock lot only:
46
MOQ for In Stock Qty:
55
MOQ for out of Stock Qty:
660
Multiple:
55
Factory Lead-Time
9 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$5.368
$5.368
55
$4.880
$268.400
110
$4.750
$522.500
275
$4.600
$1,265.000
550
$4.580
$2,519.000
660
$4.490
$2,963.400
1,320
$4.380
$5,781.600
1,980
$4.370
$8,652.600
2,640 +
$4.250
$11,220.000
