2311767-1 by te connectivity / amp brand
Image is representational - see mfr. specs
DATA SHEET

2311767-1

TE Connectivity / AMP Brand

AMPL REC, HD20, R/A, 15P, THREADED, .318 .. see full description

RoHS Compliant
Tray Packaging
Accessories
Accessories
This product is backed by Ecco Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
2311767-1
RoHS:
Yes
HTS:
8536694040
COO:
CH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
70
Package Type:
Tray
Mating Retention Type:
Threaded Inserts, 4-40 UNC
Connector & Contact Terminates To:
Printed Circuit Board
Connector System:
Wire-to-Board
Circuit Application:
Signal
Number of Positions:
15
Packaging Method:
Tray
Connector & Housing Type:
Receptacle
Contact Current Rating (Max):
3 A
PCB Mount Orientation:
Right Angle
Mating Retention:
With
Connector Profile:
Standard
PCB Mount Retention Type:
Boardlock
Number of Rows:
2
Housing Material:
PBT GF
Termination Method to Printed Circuit Board:
Through Hole - Solder
Connector Mounting Type:
Board Mount
PCB Mount Retention:
With
Centerline (Pitch):
.109 in, 2.77 mm
Operating Temperature Range:
-55 – 85 °C, -67 – 185 °F
Row-to-Row Spacing:
.111 in, 2.84 mm
Connector Shell Size:
2
Contact Shape & Form:
Round
Primary Product Color:
Black
The TE Connectivity / AMP Brand part 2311767-1 is an AMPL REC, HD20, R/A connector with 15 pins and a threaded design. It is designed to provide a secure and reliable connection in a variety of applications. With a compact and right angle design, it is perfect for situations where space is limited. The connector features a threaded design, allowing for a secure and robust connection. With a pin count of 15, it is suitable for a range of applications. Overall, the TE Connectivity / AMP Brand part 2311767-1 is a high-quality connector that is built to last.
Search Keywords:
23117671
IN STOCK: 0
MOQ for out of Stock Qty:
2500
Factory Lead-Time
13 Weeks
Price (USD)
Quantity
Unit Price
Ext. Price
1
$6.204
$6.204
100
$5.560
$556.000
250
$5.480
$1,370.000
578
$5.400
$3,121.200
1,155
$2.860
$3,303.300
1,733
$2.010
$3,483.330
2,310
$1.970
$4,550.700
2,500 +
$5.640
$14,100.000
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
1734355-1
1734355-1
